Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Coating Type | AlCrN |
| Material | Solid Carbide |
| Cutting Diameter | 20mm |
| MFR Part No. | 7716339 |
| Coating Process Type | PVD |
| Coolant Entry Style | Without Coolant |
| Maximum Ramping Angle | 7\u00b0 |
| Rotational Speed Maximum | 13200 1/min |
| Basic Standard Group | Coromant |
| Weight | 0.42kg |
| Grade | 1730 |
| Connection Diameter | 20mm |
| Unit Measured | Metric |
| Maximum Cutting Depth | 42mm |
| CoroPak | 20.1 |
| Through Hole Function Property | Yes |
| Functional Length | 109.6mm |
| Maximum Depth of Cut | 42mm |
| Center Cutting Capability | Yes |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Standards Met | COROMANT |
| Usable Length | 42mm |
