Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Coolant Entry Style | Without Coolant |
| Maximum Cutting Depth | 34mm |
| Rotational Speed Maximum | 22800 1/min |
| Material | Solid Carbide |
| Cutting Diameter | 16mm |
| Usable Length | 34mm |
| Center Cutting Capability | Yes |
| Functional Length | 97mm |
| CoroPak | 20.1 |
| Grade | 1740 |
| Coating Type | AlTiN |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Standards Met | COROMANT |
| Maximum Ramping Angle | 5\u00b0 |
| Maximum Depth of Cut | 34mm |
| Basic Standard Group | Coromant |
| Unit Measured | Metric |
| Coating Process Type | PVD |
| Through Hole Function Property | Yes |
| MFR Part No. | 7716335 |
| Connection Diameter | 16mm |
| Weight | 0.22kg |
