Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Connection Diameter | 6mm |
| Weight | 0.74kg |
| Through Hole Function Property | Yes |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coating Type | AlTiN |
| Unit Measured | Metric |
| CoroPak | 20.1 |
| Functional Length | 129.5mm |
| Maximum Cutting Depth | 52mm |
| Maximum Ramping Angle | 5\u00b0 |
| Grade | 1740 |
| Standards Met | COROMANT |
| Material | Solid Carbide |
| Center Cutting Capability | Yes |
| MFR Part No. | 7716340 |
| Maximum Depth of Cut | 52mm |
| Usable Length | 52mm |
| Basic Standard Group | Coromant |
| Coolant Entry Style | Without Coolant |
| Coating Process Type | PVD |
| Rotational Speed Maximum | 8200 1/min |
| Cutting Diameter | 25mm |
