Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Coolant Entry Style | Without Coolant |
| Cutting Diameter | 10mm |
| Maximum Depth of Cut | 22mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Grade | 1730 |
| Coating Type | AlCrN |
| Material | Carbide |
| Basic Standard Group | Coromant |
| CoroPak | 20.1 |
| Unit Measured | Metric |
| MFR Part No. | 7716348 |
| Corner Radius | 2mm |
| Maximum Cutting Depth | 22mm |
| Usable Length | 22mm |
| Through Hole Function Property | Yes |
| Coating Process Type | PVD |
| Maximum Ramping Angle | 7\u00b0 |
| Center Cutting Capability | Yes |
| Functional Length | 72mm |
| Rotational Speed Maximum | 72600 1/min |
| Standards Met | COROMANT |
| Connection Diameter | 10mm |
