Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| ISO Cutting Tool Material | Coated WC or Cermet |
| CoroPak | 20.1 |
| Maximum Cutting Depth | 52mm |
| Coating Type | AlCrN |
| Maximum Depth of Cut | 52mm |
| Functional Length | 129.5mm |
| Coolant Entry Style | Without Coolant |
| Connection Diameter | 6mm |
| Usable Length | 52mm |
| Standards Met | COROMANT |
| Basic Standard Group | Coromant |
| Center Cutting Capability | Yes |
| Coating Process Type | PVD |
| Weight | 0.75kg |
| Maximum Ramping Angle | 7\u00b0 |
| Cutting Diameter | 25mm |
| Through Hole Function Property | Yes |
| Grade | 1730 |
| Rotational Speed Maximum | 8200 1/min |
| MFR Part No. | 7716341 |
| Unit Measured | Metric |
| Material | Solid Carbide |
