Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Through Hole Function Property | Yes |
| Coolant Entry Style | 1 |
| Coating Process Type | PVD |
| Unit Measured | Imperial |
| Standards Met | COROMANT |
| Corner Radius | 1.524mm |
| Cutting Diameter | 19.05mm |
| MFR Part No. | 7858321 |
| Connection Diameter | 19.05mm |
| Basic Standard Group | Coromant |
| Product Type | Solid Carbide Endmill |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Cutting Depth | 41.27mm |
| Grade | 1725 |
| Shank Type | Weldon |
| CoroPak | 20.2 |
| Rotational Speed Maximum | 40000 1/min |
| Weight | 0.37kg |
| Coating Type | TiAlN |
| Functional Length | 107.95mm |
| Center Cutting Capability | No |
| Material | Solid Carbide |
| Maximum Depth of Cut | 41.27mm |
| Usable Length | 49.212mm |
| Maximum Ramping Angle | 5\u00b0 |
