Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Maximum Cutting Depth | 26mm |
| Center Cutting Capability | Yes |
| Cutting Diameter | 12mm |
| Coolant Entry Style | Without Coolant |
| Coating Type | AlTiN |
| Usable Length | 26mm |
| MFR Part No. | 7716354 |
| Standards Met | COROMANT |
| Through Hole Function Property | Yes |
| Basic Standard Group | Coromant |
| Coating Process Type | PVD |
| CoroPak | 20.1 |
| Weight | 0.11kg |
| Material | Solid Carbide |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Depth of Cut | 26mm |
| Maximum Ramping Angle | 5\u00b0 |
| Functional Length | 83mm |
| Corner Radius | 1.5mm |
| Grade | 1740 |
| Unit Measured | Metric |
| Rotational Speed Maximum | 43800 1/min |
| Connection Diameter | 12mm |
