Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Corner Radius | 4mm |
| Usable Length | 34mm |
| Material | Solid Carbide |
| Through Hole Function Property | Yes |
| Center Cutting Capability | Yes |
| Rotational Speed Maximum | 22800 1/min |
| Coolant Entry Style | Without Coolant |
| Maximum Depth of Cut | 34mm |
| CoroPak | 20.1 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coating Process Type | PVD |
| Maximum Ramping Angle | 5\u00b0 |
| Standards Met | COROMANT |
| MFR Part No. | 7716371 |
| Unit Measured | Metric |
| Grade | 1740 |
| Basic Standard Group | Coromant |
| Coating Type | AlTiN |
| Cutting Diameter | 16mm |
| Connection Diameter | 63mm |
| Weight | 0.23kg |
| Functional Length | 97mm |
| Maximum Cutting Depth | 34mm |
