Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Coolant Entry Style | Without Coolant |
| Cutting Diameter | 19.05mm |
| Unit Measured | Metric |
| Standards Met | COROMANT |
| Basic Standard Group | Coromant |
| Center Cutting Capability | Yes |
| Maximum Ramping Angle | 5\u00b0 |
| Coating Type | AlTiN |
| Grade | 1740 |
| Coating Process Type | PVD |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Through Hole Function Property | Yes |
| Connection Diameter | 19.05mm |
| CoroPak | 20.1 |
| Corner Radius | 2.286mm |
| MFR Part No. | 7716377 |
| Rotational Speed Maximum | 15300 1/min |
| Usable Length | 41.275mm |
| Material | Solid Carbide |
| Maximum Depth of Cut | 41.27mm |
| Functional Length | 109.6mm |
| Maximum Cutting Depth | 41.27mm |
