Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Rotational Speed Maximum | 15300 1/min |
| Maximum Cutting Depth | 41.27mm |
| Coating Type | AlTiN |
| Connection Diameter | 19.05mm |
| Maximum Depth of Cut | 41.27mm |
| Center Cutting Capability | Yes |
| Cutting Diameter | 19.05mm |
| Basic Standard Group | Coromant |
| Usable Length | 41.275mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Weight | 0.36kg |
| Material | Solid Carbide |
| MFR Part No. | 7716375 |
| Corner Radius | 1.524mm |
| Grade | 1740 |
| Coolant Entry Style | Without Coolant |
| Through Hole Function Property | Yes |
| Maximum Ramping Angle | 5\u00b0 |
| CoroPak | 20.1 |
| Functional Length | 109.6mm |
| Standards Met | COROMANT |
| Unit Measured | Metric |
| Coating Process Type | PVD |
