Product Range: CoroMill PluraTool Type: Thread millingSmall diameter shoulder milling with close tolerancesCoroMill Plura is a range of high quality solid carbide end mills that offer productive, efficient, and perfectly reliable milling solutions. Featuring tools for heavy roughing, finishing, and thread milling, CoroMill Plura works in various applications and materials, including difficult-to-cut materials and very hard steels up to 63 HRc.
| Maximum Depth of Cut | 42mm |
| Coolant Entry Style | Without Coolant |
| Connection Diameter | 20mm |
| Corner Radius | 3mm |
| Grade | 1740 |
| Center Cutting Capability | Yes |
| Coating Type | AlTiN |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Rotational Speed Maximum | 13200 1/min |
| Usable Length | 42mm |
| Coating Process Type | PVD |
| Maximum Ramping Angle | 5\u00b0 |
| Functional Length | 109.6mm |
| Cutting Diameter | 20mm |
| MFR Part No. | 7716384 |
| Unit Measured | Metric |
| Standards Met | COROMANT |
| Maximum Cutting Depth | 42mm |
| Through Hole Function Property | Yes |
| CoroPak | 20.1 |
| Weight | 0.4kg |
| Basic Standard Group | Coromant |
| Material | Solid Carbide |
