Product Range: CoroMill 327Tool Type: Thread millingA versatile cutter which can be used for many types of grooves, threads and chamfers; machining of eccentric components such as gearbox casings, and high volume assemblies, mainly in machining centres and rotating units in lathes.Features & Benefits- Flexible cutter with multiple edges for many types of applications- Low cutting forces- Large program with different shank lengths and diametersApplication- Circlip grooving, Thread milling, Groove milling, Chamfering, both front and back
| Body Half Taper Angle | 0\u00b0 |
| Body Diameter | 0.35in |
| Coolant Entry Style | Without Coolant |
| MFR Part No. | 26537645 |
| Functional Diameter | 20mm |
| CoroPak | 14.1 |
| Functional Length | 24.65mm |
| Connection Diameter | 21mm |
| Rotational Speed Maximum | 40000 1/min |
| Damping Property | No |
| Coolant Exit Style | 0 |
| Body Material | Steel |
| Unit Measured | Metric |
| Through Hole Function Property | Yes |
