For drilling into general steel, cast steel, cast iron,
chilled cast iron, malleable cast iron, non-ferrous
heavy and light metal, and abrasive plastic, self-centering.
Point angle: 140, Tolerance of diameter: m7,
tolerance of shank: h6. Manufactured to DIN 6537.
| Series | 5511 |
| Shank Diameter | 12mm |
| Flute Length | 71mm |
| Point Angle | 140\u00b0 |
| Material | Carbide |
| Finish/Coating | FIREX\u00ae (TiN+TiAlN) |
| Point Type | SU |
| Shank Diameter Tolerance | H6 |
| MFR Part No. | 05511 010.320 |
| Cutting Direction | Right Hand |
| Product Type | Drills |
| Carbide Drill Type | Carbide High Performance |
| Standards Met | DIN 6537 |
| Helix Type | RT 100 U |
| Flute Type | Spiral |
| Coolant Delivery | Coolant Through |
| Drill Diameter | 10.32mm |
| Drill Diameter Tolerance | M7 |
| Number of Flutes | 2 |
| Overall Length | 118mm |
