Guhring standard production taps are marked with colour rings to help you quickly and confidently choose the correct tool for your job. Each ring relates to the unique machining behaviours of different materials as dictated by their type and condition.
Manufactured from HSS-E steel to DIN 371.
For blind and through holes
To form C
Size range M3 to M10
TiN coated
Tolerance to 6HX
| Thread Size | M6 |
| Thread Length | 16.00mm |
| Overall Length | 80mm |
| Series | 5598 |
| Tap Type | Fluteless |
| Product Type | Machine Taps |
| Material | Cobalt High Speed Steel |
| Shank Diameter | 6.0mm |
| Coolant Delivery | External |
| Class of Fit | 6HX |
| Thread Direction | Right Hand |
| Thread Standard | Metric Coarse |
| Square Width | 4.9mm |
| Finish/Coating | TiN |
| Dimensions Standard | DIN 371 |
| Material Grade | M35 |
| Pitch | 1.0 |
| MFR Part No. | 05598 006.000 |
