Guhring standard production taps are marked with colour rings to help you quickly and confidently choose the correct tool for your job. Each ring relates to the unique machining behaviours of different materials as dictated by their type and condition.
Manufactured from HSS-E steel to DIN 371.
Spiral point for through holes
Red ring
To form B
Size range M3 to M10
Steam tempered
Tolerance to ISO 2/6H
| Square Width | 6.2mm |
| Thread Length | 20.00mm |
| Thread Direction | Right Hand |
| Finish/Coating | Steam Tempered |
| Ring Colour | Red |
| Helix Angle | 0 |
| Pitch | 1.25 |
| Shank Diameter | 8.0mm |
| MFR Part No. | 05558 008.000 |
| Material | Cobalt High Speed Steel |
| Overall Length | 90mm |
| Tapping Depth | 35.0mm |
| Class of Fit | ISO2/6H |
| Coolant Delivery | External |
| Series | 5558 |
| Thread Standard | Metric Coarse |
| Dimensions Standard | DIN 371 |
| Thread Size | M8 |
| Material Grade | M35 |
| Tap Type | Spiral Point |
