Hole depth: 3x Dc. Cylindrical shank - flat according to ISO 9766.
Stronger drill body with new surface treatment can withstand higher feeds. Wiper geometry for best surface finish. Optimized chip channels for accelerated chip evacuation. Easy identification due to laser marking with drill-, insert- and screw codes on the drill shank.
| Insert Type | 04 |
| Depth to Diameter Ratio | 3xD |
| Flute Type | Helical |
| Body Length | 76mm |
| Maximum Drilling Depth | 72mm |
| Drilling System | CoroDrill 880 |
| Product Type | CoroDrill |
| Series | 880 |
| Reference Length | 95mm |
| Shank Type | Cylindrical |
| Full Toolholder Code | D2390L25-03 |
| Size | 23.9mm |
| Shank Diameter | 25mm |
| Overall Length | 151mm |
| Shank Length | 56mm |
| Flute Length | 89.94mm |
| Diameter | 23.9mm |
| Coolant Delivery | Coolant Through |
| Standards Met | ISO 9766 |
| MFR Part No. | 12002911 |
