£52.80
1
of
3
Loading...
Product Range: CoroDrill DS20Tool Type: Indexable drills47DC insert drill that offers reliability, predictability and outstanding penetration rates.Features & Benefits- First choice for general 4-7 DC drilling operations- Secure and reliable cutting process with high productivity- Versatile drill with good chip formation over a broad cutting data range- Optimized chip control and chip evacuation
| Functional Length | 289.2232mm |
| Overall Length | 360.4998mm |
| Rotational Speed Maximum | 3000 1/min |
| Connection Diameter | 38.1mm |
| Cutting Diameter | 42.8498mm |
| Tool Cutting Edge Angle | 81\u00b0 |
| Through Hole Function Property | Yes |
| Coating Type | TiAlN |
| Usable Length | 258.3754mm |
| Usable Length Diameter Ratio | 6.029792437771 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| MFR Part No. | 7548974 |
| Maximum Adjustment Limit | 3.23mm |
| Unit Measured | Imperial |
| Coating Process Type | PVD |
| CoroPak | 20.2 |
| Weight | 2.67kg |
