Product Range: Coromant U
| Unit Measured | Metric |
| Insert Mounting Style | Screw/Clamp |
| Weight | 1.7g |
| Insert Size/Shape | CoroDrill 881/U LC0303xx |
| CoroPak | 96.3 |
| Insert Thickness | 3.175mm |
| Insert Usage Code | Peripheral |
| Coating Process Type | PVD |
| Grade | 1020 |
| Cutting Edge Count | 2 |
| Insert Rake Angle | 18\u00b0 |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Through Hole Function Property | Yes |
| Coating Type | TiN |
| Corner Radius | 0.8mm |
| MFR Part No. | 5735048 |
| Fixing Hole Diameter | 2.5mm |
