The insert limit is Tmax 18 mm. If deeper penetration is required the insert should be modified into single-ended by the user.
Extractors not included.
| Cutting Height | 25mm |
| Workpiece Diameter | 35 |
| Blade Width | 2.5mm |
| MFR Part No. | 2301263 |
| Maximum Grooving Depth | 17.5mm |
| Blade Style | DO-GRIP HOLDER |
| ISO Designation | DGTL 2525-3 |
| Minimum Grooving Width | 3mm |
| Insert Style | DGN/R/L |
| Series | Do-Grip |
| Cutting Application | Grooving | Parting |
| Seat Size | 3 |
| Number of Pockets | 1 |
| Blade Type | Tool Holder |
| Blade Length | 150mm |
| Maximum Grooving Width | 3.18mm |
| Blade Height | 25mm |
