CCMT turning inserts are 80 rhombic shaped inserts. with a single-sided, 7 positive relief angle for semi-finish and finish cutting. "M" tolerance edge condition for general with chip breaking in moderate feed range. Their positive rake and low cutting forces make them ideal for use on a wide range of materials, including non-ferrous and exotic alloys.
Features and Benefits
A tough sub-micron substrate for durability and performance
Good cutting performance at low-to-medium cutting speeds
Suitable for use on heat resistant alloys, austenitic stainless steel and hard steel
Standards
Insert Grade IC907
| Cutting Edge Length | 9.7mm |
| Manufacturer Grade | IC907 |
| Cutting Direction | Neutral |
| Chipbreaker | SM |
| Pack Quantity | 1 |
| Finish/Coating | TiAIN/TiN |
| Insert Style | CCMT |
| Clearance Angle | 7\u00b0 |
| Inscribed Circle | 9.525mm |
| Insert Size | 09T308 |
| ISO Category Grade | H | K | M | N | P | S |
| Corner Radius | 0.8 |
| Material | Carbide |
| ISO Category | H | K | M | N | P | S |
| ISO Cut | H05 to H15 | K15 to K30 | M05 to M20 | N05 to N20 | P10 to P30 | S05 to S20 |
| Material Application | Cast Iron | Hardened Steel | High-Temperature Alloys | Nonferrous Metals | Nonferrous Metals | Steels |
| ISO Designation | CCMT 09T308-SM |
| MFR Part No. | 5504774 |
| Thickness | 3.97mm |
| Shape | 80\u00b0 Rhombic |
