Series A777 are manufactured from HSS-Co for toughness, excellent for drilling higher tensile, tougher materials. 135 split point for improved precision and finish (over 1.5mm).
Features and Benefits
High speed steel and cobalt construction for added toughness
Excellent for drilling higher tensile, tougher materials
135 split point for improved precision and finish (over 1.5mm)
Standards
BS 328, DIN 338
| Overall Length | 57mm |
| Drill Diameter Tolerance | H8 |
| Flute Type | Spiral |
| Material | Cobalt High Speed Steel |
| Cutting Direction | Right Hand |
| Standards Met | BS 328 | DIN 338 |
| Flute Construction | Ground flutes |
| Flute Length | 30mm |
| Shank Diameter Tolerance | H8 |
| MFR Part No. | A7773/32 |
| Point Angle | 135\u00b0 |
| Product Type | Jobber Drills |
| Drill Diameter | 3/32in |
| Point Type | Split Point |
| Number of Flutes | 2 |
| Series | A777 |
| Finish/Coating | Bronze |
| Helix Type | Normal Helix |
| Coolant Delivery | External |
| Drill Diameter Inch | 3/32in |
