Regular Series - 2 Flute - Inch
For optimum performance and maximum swarf removal when plunging, slotting and routing in most materials including brass, aluminium, non ferrous and other soft materials. Manufactured to USCTi Standards.
Inch Tolerances
Diameter: Over 1/16" ~ up to 1/4". Tolerance: +0.000, -0.002.
Diameter: Over 1/4" ~ up to 1". Tolerance: +0.000, -0.003.
| ISO Designation | N |
| Milling Cutter Type | Slot Drill |
| Shank Diameter | 1/8in |
| Material | Carbide |
| Finish/Coating | Uncoated |
| Flute Length | 9/32in |
| Cutter Diameter | 3/32in |
| Length Type | Regular |
| Shank Type | Plain Round |
| Flute Type | Helical |
| Standards Met | USCTI Standards |
| Material Application | Aluminium | Nonferrous Metals | Other Soft Materials |
| Cutting Direction | Right Hand |
| Milling Application | Plunging | Routing | Slotting |
| Material Grade | Micrograin |
| Coolant Delivery | External |
| Overall Length | 1.1/2in |
| Cutter Style | Ball Nose |
| Plunge Type | Non-centre Cutting |
| Number of Flutes | 2 |
| End Mill Type | Slot Drill |
| System of Measurement | Inch |
