Long Series - 2 Flute - Metric
For optimum performance and maximum swarf removal when plunging, slotting and routing in most materials including brass, aluminium, non ferrous and other soft materials. Manufactured to USCTi Standards.
Metric Tolerances
Diameter: Over 1.00 ~ up to 6.00. Tolerance: +0.000, -0.050.
Diameter: Over 6.00 ~ up to 25.00. Tolerance: +0.000, -0.080.
| End Mill Type | Slot Drill |
| Coolant Delivery | External |
| Flute Length | 50.0mm |
| Shank Type | Plain Round |
| Number of Flutes | 2 |
| Finish/Coating | Uncoated |
| Cutter Diameter | 6.0mm |
| Product Type | Slot Drills |
| Flute Type | Helical |
| Length Type | Long |
| MFR Part No. | EDP43506 |
| Plunge Type | Non-centre Cutting |
| Standards Met | USCTI Standards |
| Cutting Direction | Right |
| Material | Solid Carbide |
| Overall Length | 150.0mm |
| Shank Diameter | 6.0mm |
