Lubrication grooves are a feature of all Thredfloer taps of M3.0 and over. These allow lubrication to reach the end of the tap to maintain tool life and to prevent damage from hydraulic blow out.
Suitable for the following Material Groups
Metric Coarse
HSS- EV, bright finish. Tolerance 6H.
Manufactured
to DIN 371.
| Material Application | Brass | Copper | Mild Steel |
| Coolant Delivery | External |
| Thread Size | M8 |
| Overall Length | 90mm |
| Tap Type | Fluteless |
| Class of Fit | 6H |
| Square Width | 6.2mm |
| Thread Length | 22.00mm |
| Thread Direction | Right Hand |
| Tapping Depth | 18.0mm |
| Shank Diameter | 8.0mm |
| Finish/Coating | Bright |
| Pitch | 1.25 |
| Ring Colour | No Coloured Ring |
| Material | Vanadium High Speed Steel |
| Thread Standard | Metric Coarse |
| Dimensions Standard | DIN 371 |
| Material Grade | M35 |
| Product Type | Fluteless Tap |
