Lubrication grooves are a feature of all Thredfloer taps of M3.0 and over. These allow lubrication to reach the end of the tap to maintain tool life and to prevent damage from 'hydraulic blow out
Suitable for the following Material Groups
Metric Coarse
HSS, TiN coated. Tolerance 6H.
Manufactured
to DIN 371.
| Ring Colour | No Coloured Ring |
| Shank Diameter | 8.0mm |
| Overall Length | 90mm |
| Finish/Coating | TiN |
| Class of Fit | 6H |
| Thread Direction | Right Hand |
| Material Grade | M2 |
| Material | HSS |
| Tapping Depth | 18.0mm |
| Material Application | Aluminium | Aluminium Alloys | Magnesium | Zinc |
| Pitch | 1.25 |
| Thread Size | M8 |
| Thread Length | 22.00mm |
| Coolant Delivery | External |
| Thread Standard | Metric Coarse |
| Dimensions Standard | DIN 371 |
| Tap Type | Fluteless |
| Square Width | 6.2mm |
