Manufactured from top quality sintered steels. For use on a wide range of applications from roughing to finishing. Manufactured to BS1296:Part 3:1978.
Boring Tools
| Shank Height | 16.00mm |
| Tool Number | 50B |
| Material Grade | HSS |
| Side Clearance Angle | 6\u00b0 |
| Approach Angle | -45\u00b0 |
| Product Type | Lathe Tool |
| Standards Met | BS 1296 Part 3 |
| Cutting Direction | Right Hand |
| Shank Width | 16.00mm |
| Trail Angle | 30\u00b0 |
| Corner Radius Angle | -6\u00b0 |
| Cutting Angle | 90\u00b0 |
| Tip Material | HSS |
| Tool Type | Through Boring |
| Top Rake Angle | 5\u00b0 |
| Overall Length | 200.00mm |
| Front Clearance Angle | 6\u00b0 |
