Dormer MTT-X Series taps are manufactured from HSS-X1 Steel with a bright finish, they are right hand cutting. Premium substrate with steam oxide surface
treatment reduces wear and prevents chip welding
in abrasive or harder ferrous materials.
Features
Manufactured to ISO 529
Spiral Flute for threading blind holes.
Taper lead to DIN form C.
Tapping tolerance to 6H.
Max Depth 2.5 x D.
Helix angle 48.
| Material | Cobalt High Speed Steel |
| ISO Category | K | M | P |
| Number of Flutes | 3 |
| Dimensions Standard | ISO 529 |
| Thread Length | 24mm |
| Teeth per Inch | 18 |
| Finish/Coating | Steam Tempered |
| Tap Type | Spiral Point |
| Class of Fit | 2B |
| Overall Length | 95mm |
| Series | E031 |
| Ring Colour | No Coloured Ring |
| Pitch | 18 |
| Product Type | Machine Taps |
| Shank Diameter | 11.2mm |
| Thread Standard | UNF |
| Thread Size | 9/16\ |
| Thread Direction | Right Hand |
| Square Width | 9mm |
| MFR Part No. | E0319/16 |
