Breaking Torque wrench SE 14x18 40-200 Nm 050310

Use: Controlled screw tightening in the range from 40 - 200 Nm Serial / production-line Extremely long-term work Features: Pre-set production torque wrench - without scale With 9x12 mm rectangular-cavity-end For bi-directional tightening (the wrench only has to be turned by 180!) Working accuracy: +/- 4 % tolerance of set torque Acc. to DIN EN ISO 6789, traceable to national standards Breaking of the handgrip by 20 when the pre-set torque value is achieved makes over-tightening unlikely Automatic resetting to the starting position Lightweight, but robust and corrosion-resistant construction design Very convenient non-slip rubber handgrip No. TBN 2 G: EPA (Electrostatic Protected Area) compliant, for use in electrostatically sensitive applications The pre-setting can be made at the factory or by the user on suitable torque testers If ordering, please specify the Nm value - if a fixed factory pre-setting is desired (price on request) Scope of delivery: Torque wrench TBN Breaking Torque wrench Special adjusting key for changing the pre-set torque value Test certificate acc. to DIN EN ISO 6789 Delivery in sturdy cardboard packaging

Material	Tubular Steel Construction
Length	610mm
Tightening Direction	Left and right
Standards Met	DIN EN ISO 6789-2
Product Type	Torque Wrenches
Trigger Mechanism	Long travel triggering
Drive Connector Rectangular	14 x 18mm
Precision	+/- 4 %
Drive Type	Rectangular cavity
