Weight Of Item: 0.0072 kg
Fixing Hole Diameter: 3.81 mm
Grade: 3210
Inscribed Circle Diameter: 9.525 mm
Clearance Angle Major: 0 deg
Insert Mounting Style Code: Screw/Clamp
Insert Size And Shape: TN1604
Cutting Edge Count: 6
Hand: N
Chip Breaker Manufacturer'S Designation: WM
| Grade | 3210 |
| Coating Process Type | CVD |
| Insert Size/Shape | TN1604 |
| Unit Measured | Metric |
| Wiper Edge Property | Yes |
| Insert Shape | Triangle |
| Hand Preference | Neutral |
| Inscribed Circle | 9.525mm |
| Fixing Hole Diameter | 3.81mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Cutting Edge Count | 6 |
| Weight | 7.2g |
| Clearance Angle Major | 0\u00b0 |
| Insert Mounting Style | Screw/Clamp |
| Clearance Angle | 0\u00b0 |
| Insert Thickness | 4.7625mm |
| Through Hole Function Property | Yes |
| Inscribed Circle Diameter | 9.53mm |
| MFR Part No. | 5754796 |
| CoroPak | 15.2 |
| Insert Style | Screw/Clamp |
| Finish/Coating | TiCN+Al2O3+TiN |
| Corner Radius | 1.1906mm |
| Coating Type | TiCN+Al2O3+TiN |
