Tool type: Face millingLight-cutting face mill for heavy roughing and mirror finishing. Milling cutters for high metal removal and mirror finish. The cutter is designed with enhanced corners to reduce burr formation and frittering of the component.Features & Benefits- First choice for mixed production- 4 cutting edges- Shim for extra security- True 45 degrees- Close tolerance combined with the wiper insert for superior surface finish- Wide range of grades and geometries including ceramic and CBN grades- Multipurpose tool. Face milling, boring possibilities, ramping and plunge millingApplicationFace milling applications in all types of materials
| Unit Measured | Metric |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coating Type | TiCN+TiN |
| Insert Mounting Style | Screw/Clamp |
| Insert Rake Angle | 15\u00b0 |
| Grade | 1025 |
| Wiper Edge Length | 2.1mm |
| Wiper Edge Radius | 200mm |
| Insert Style | Screw/Clamp |
| CoroPak | 96.3 |
| Insert Shape | Square |
| Inscribed Circle | 13.4mm |
| Insert Size/Shape | CoroMill 245 -12T3 |
| Finish/Coating | TiCN/TiN |
| Weight | 7.5g |
| Hand Preference | Right |
| Corner Radius | 1.5mm |
| Maximum Depth of Cut | 6.5mm |
| Inscribed Circle Diameter | 13.4mm |
| MFR Part No. | 5743889 |
| Cutting Edge Count | 4 |
| Insert Thickness | 3.96875mm |
| Fixing Hole Diameter | 4.1mm |
| Maximum Cutting Depth | 6.5mm |
| Coating Process Type | PVD |
| Through Hole Function Property | Yes |
