Tool type: Face millingLight-cutting face mill for heavy roughing and mirror finishing. Milling cutters for high metal removal and mirror finish. The cutter is designed with enhanced corners to reduce burr formation and frittering of the component.Features & Benefits- First choice for mixed production- 4 cutting edges- Shim for extra security- True 45 degrees- Close tolerance combined with the wiper insert for superior surface finish- Wide range of grades and geometries including ceramic and CBN grades- Multipurpose tool. Face milling, boring possibilities, ramping and plunge millingApplicationFace milling applications in all types of materials
| Hand Preference | Right |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Depth of Cut | 6.5mm |
| Insert Size/Shape | CoroMill 245 -12T3 |
| Corner Radius | 1.5mm |
| Fixing Hole Diameter | 4.1mm |
| Coating Process Type | PVD |
| Coating Type | TiAlN |
| Insert Style | Screw/Clamp |
| Insert Rake Angle | 6\u00b0 |
| Inscribed Circle | 13.4mm |
| Inscribed Circle Diameter | 13.4mm |
| MFR Part No. | 5743987 |
| Wiper Edge Length | 2mm |
| Insert Mounting Style | Screw/Clamp |
| Cutting Edge Count | 4 |
| Grade | 1020 |
| Finish/Coating | TiAlN |
| Insert Shape | Square |
| Through Hole Function Property | Yes |
| Insert Thickness | 3.96875mm |
| Unit Measured | Metric |
| Weight | 8.5g |
| Maximum Cutting Depth | 6.5mm |
| CoroPak | 6.2 |
