Tool type: Face millingLight-cutting face mill for heavy roughing and mirror finishing. Milling cutters for high metal removal and mirror finish. The cutter is designed with enhanced corners to reduce burr formation and frittering of the component.Features & Benefits- First choice for mixed production- 4 cutting edges- Shim for extra security- True 45 degrees- Close tolerance combined with the wiper insert for superior surface finish- Wide range of grades and geometries including ceramic and CBN grades- Multipurpose tool. Face milling, boring possibilities, ramping and plunge millingApplicationFace milling applications in all types of materials
| Insert Rake Angle | 15\u00b0 |
| Insert Style | Screw/Clamp |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Maximum Cutting Depth | 6.5mm |
| Coating Type | TiCrN+Al2O3+TiN |
| Grade | 2040 |
| Corner Radius | 1.5mm |
| Through Hole Function Property | Yes |
| Wiper Edge Radius | 200mm |
| Unit Measured | Metric |
| Insert Size/Shape | CoroMill 245 -12T3 |
| Insert Mounting Style | Screw/Clamp |
| Coating Process Type | CVD |
| Insert Thickness | 3.96875mm |
| Inscribed Circle | 13.4mm |
| Finish/Coating | TiCrN+Al2O3+TiN |
| Weight | 6.7g |
| Wiper Edge Length | 2.1mm |
| Hand Preference | Right |
| CoroPak | 99.2 |
| Cutting Edge Count | 4 |
| Inscribed Circle Diameter | 13.4mm |
| Maximum Depth of Cut | 6.5mm |
| Fixing Hole Diameter | 4.1mm |
| MFR Part No. | 5744018 |
| Insert Shape | Square |
