Insert Size And Shape: TN1604
Fixing Hole Diameter: 4.6 mm
Cutting Edge Count: 6
Chip Breaker Manufacturer'S Designation: WM
Weight Of Item: 0.0059 kg
Insert Mounting Style Code: Screw/Clamp
Hand: N
Grade: 4425
Clearance Angle Major: 0 deg
Inscribed Circle Diameter: 9.525 mm
| Weight | 5.9g |
| Coating Process Type | CVD |
| Finish/Coating | TiCN+Al2O3+TiN |
| CoroPak | 21.2 |
| Unit Measured | Metric |
| Wiper Edge Property | Yes |
| MFR Part No. | 8019704 |
| Corner Radius | 1.1906mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Clearance Angle Major | 0\u00b0 |
| Hand Preference | Neutral |
| Clearance Angle | 0\u00b0 |
| Grade | 4425 |
| Insert Shape | Triangle |
| Insert Style | Screw/Clamp |
| Inscribed Circle | 9.525mm |
| Insert Mounting Style | Screw/Clamp |
| Coating Type | TiCN+Al2O3+TiN |
| Insert Thickness | 4.7625mm |
| Through Hole Function Property | Yes |
| Cutting Edge Count | 6 |
| Inscribed Circle Diameter | 9.53mm |
| Insert Size/Shape | TN1604 |
| Fixing Hole Diameter | 4.6mm |
