Insert Mounting Style Code: Screw/Clamp
Fixing Hole Diameter: 4.6 mm
Hand: N
Cutting Edge Count: 6
Clearance Angle Major: 0 deg
Weight Of Item: 0.01 kg
Chip Breaker Manufacturer'S Designation: WM
Grade: 4415
Inscribed Circle Diameter: 12.7 mm
Insert Size And Shape: WN0804
| Wiper Edge Property | Yes |
| Insert Mounting Style | Screw/Clamp |
| Hand Preference | Neutral |
| Through Hole Function Property | Yes |
| Insert Style | Screw/Clamp |
| Coating Process Type | CVD |
| Inscribed Circle | 12.7mm |
| Insert Size/Shape | WN0804 |
| Insert Shape | Trigon |
| MFR Part No. | 8021315 |
| Grade | 4415 |
| Insert Thickness | 4.7625mm |
| Weight | 10g |
| Finish/Coating | TiCN+Al2O3+TiN |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Cutting Edge Count | 6 |
| Inscribed Circle Diameter | 12.7mm |
| Corner Radius | 1.1906mm |
| Coating Type | TiCN+Al2O3+TiN |
| Clearance Angle Major | 0\u00b0 |
| Clearance Angle | 0\u00b0 |
| CoroPak | 21.2 |
| Fixing Hole Diameter | 4.6mm |
| Unit Measured | Metric |
