Hand: N
Face Land Width: 0.15 mm
Grade: 7014
Insert Mounting Style Code: Screw/Clamp
Face Land Angle: 15 deg
Cutting Edge Count: 4
Wiper Edge Length: 0.8 mm
Clearance Angle Major: 0 deg
Chip Breaker Manufacturer'S Designation: XA
Inscribed Circle Diameter: 12.7 mm
Depth Of Cut Maximum: 0.25 mm
Insert Size And Shape: CN1204
Fixing Hole Diameter: 5.156 mm
Weight Of Item: 0.0067 kg
| Inscribed Circle | 12.7mm |
| MFR Part No. | 7941843 |
| Insert Shape | Diamond 80\u00b0 |
| Insert Thickness | 4.7625mm |
| Insert Style | Screw/Clamp |
| Maximum Depth of Cut | 0.25mm |
| Unit Measured | Metric |
| Through Hole Function Property | Yes |
| Face Land Angle | 15\u00b0 |
| Insert Size/Shape | CN1204 |
| Inscribed Circle Diameter | 12.7mm |
| Maximum Cutting Depth | 0.25mm |
| Finish/Coating | Uncoated |
| Grade | 7014 |
| Wiper Edge Property | Yes |
| Coating Process Type | Uncoated |
| Clearance Angle Major | 0\u00b0 |
| Insert Mounting Style | Screw/Clamp |
| Face Land Width | 0.15mm |
| Fixing Hole Diameter | 5.156mm |
| ISO Cutting Tool Material | CBN low content |
| Weight | 6.7g |
| CoroPak | 381 |
| Coating Type | Uncoated |
| Hand Preference | Neutral |
| Wiper Edge Length | 0.8mm |
| Cutting Edge Count | 4 |
