Insert Mounting Style Code: Screw/Clamp
Hand: N
Clearance Angle Major: 0 deg
Weight Of Item: 0.047 kg
Grade: 4315
Fixing Hole Diameter: 7.8 mm
Inscribed Circle Diameter: 19.05 mm
Chip Breaker Manufacturer'S Designation: PF
Insert Size And Shape: CN1911
Cutting Edge Count: 4
| Weight | 47g |
| MFR Part No. | 7800844 |
| Insert Shape | Diamond 80\u00b0 |
| Insert Mounting Style | Screw/Clamp |
| Inscribed Circle | 19.05mm |
| Hand Preference | Neutral |
| Insert Style | Screw/Clamp |
| Clearance Angle Major | 0\u00b0 |
| Coating Process Type | CVD |
| Inscribed Circle Diameter | 19.05mm |
| Wiper Edge Property | No |
| Through Hole Function Property | Yes |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Coating Type | TiCN+Al2O3+TiN |
| Clearance Angle | 0\u00b0 |
| Unit Measured | Metric |
| Insert Thickness | 11mm |
| Finish/Coating | TiCN+Al2O3+TiN |
| Grade | 4315 |
| Fixing Hole Diameter | 7.8mm |
| Insert Size/Shape | CN1911 |
| Corner Radius | 4mm |
| CoroPak | 19.2 |
| Cutting Edge Count | 4 |
