Proto save
£2.71
Loading...
Insert Size And Shape: LN1919
Hand: N
Weight Of Item: 0.0428 kg
Grade: 4315
Insert Mounting Style Code: Screw/Clamp
Clearance Angle Major: 0 deg
Chip Breaker Manufacturer'S Designation: PM
Cutting Edge Count: 4
Fixing Hole Diameter: 6.35 mm
| Finish/Coating | TiCN+Al2O3+TiN |
| Weight | 42.8g |
| CoroPak | 19.2 |
| Insert Size/Shape | LN1919 |
| Wiper Edge Property | No |
| Grade | 4315 |
| MFR Part No. | 7800845 |
| Cutting Edge Count | 4 |
| Insert Width | 10mm |
| Unit Measured | Metric |
| Clearance Angle | 0\u00b0 |
| Coating Process Type | CVD |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Insert Style | Screw/Clamp |
| Hand Preference | Neutral |
| Insert Mounting Style | Screw/Clamp |
| Corner Radius | 4mm |
| Clearance Angle Major | 0\u00b0 |
| Through Hole Function Property | Yes |
| Insert Shape | Rectangle |
| Coating Type | TiCN+Al2O3+TiN |
| Fixing Hole Diameter | 6.35mm |
| Insert Thickness | 19.05mm |
