Clamp-on type. The modular blade allows for high rigidity and accuracy (TriForce System). Various insert types.
00 type holder
GY Series Right Hand Modular Holder & Blade For 3.00mm Grooving Width
| Compatible Shank Size | 25 |
| ISO Designation | GYM25RD-F12-050 |
| Series | GY |
| MFR Part No. | 90026721 |
| Blade Type | Modular Blade |
| First Cut Diameter | 50 to 60mm |
| Maximum Grooving Depth | 12mm |
| Maximum Grooving Width | 3mm |
| Workpiece Diameter | 50 |
| Seat Size | F |
| Compatible Modular Toolholder | GYHL2525M90-M25R | GYHR2020K00-M25R | GYHR2525M00-M25R | GYHR3225P00-M25R | GYHR3232P00-M25R |
| Coolant Delivery | External |
| Blade Style | GYM |
| Cutting Application | Face Grooving |
| Cutting Direction | Right Hand |
| Insert Style | GYM2 |
