GY Series 90 Internal Grooving Left Hand Modular Holder

GY Series Left Hand Modular Holders - 90 Type The Mitsubishi GY series of grooving and parting off toolholders are a range of tools designed to offer ultimate rigidity and accuracy for stable grooving applications. The modular system allows flexible tool selection while maintaining overall strength for stable machining. Additionally, a wide variety of inserts makes it possible to cover a diverse range of machining applications, ensuring high efficiency, high precision machining.

MFR Part No.	90023448
Maximum Grooving Depth	7mm
Workpiece Diameter	32
Cutting Height	23mm
Seat Size	G
Minimum Grooving Width	4mm
Shank Diameter	25mm
Coolant Delivery	Coolant Through
ISO Designation	GYAL25K90B-G07
Modular Toolholder	Holder with insert- holding blade attached
Cutting Application	Grooving
Centre to Cutting Tip	19mm
Cutting Direction	Left Hand
Insert Holding Type	Screw-On
Maximum Grooving Width	4mm
Head Length	40mm
Insert Style	GY1G | GY2G | GY2M
Minimum Bore Diameter	32mm
Series	GY
Toolholder Style	GYAL
Overall Length	125mm
