GY Series 90 Internal Grooving Right Hand Modular Holder

GY Series Right Hand Modular Holders - 90 Type TheGY series of grooving and parting off toolholders are a range of tools designed to offer ultimate rigidity and accuracy for stable grooving applications. The modular system allows flexible tool selection while maintaining overall strength for stable machining. Additionally, a wide variety of inserts makes it possible to cover a diverse range of machining applications, ensuring high efficiency, high precision machining.

Seat Size	G
Minimum Bore Diameter	32mm
Workpiece Diameter	to 32
MFR Part No.	90023412
Cutting Direction	Right Hand
Maximum Grooving Width	4mm
Cutting Height	23mm
Head Length	40mm
Overall Length	125mm
Toolholder Style	GYAR
Series	GY
Centre to Cutting Tip	19mm
Modular Toolholder	Holder for Modular Blade
Minimum Grooving Width	4mm
ISO Designation	GYAR25K90B-G07
Shank Diameter	20mm
Insert Holding Type	Screw-On
Maximum Grooving Depth	7mm
Cutting Application	Grooving
Insert Style	GY1G | GY2G | GY2M
