Counterbores H with a diameter of 50mm and larger are all made with a driving lip. These sizes should be used in the appropriate type M toolholder.
Dimensions (mm) H & HA
Counterbores H and HA with of 50 mm and larger are all made with a driving lip. These sizes should be used in the appropriate type M toolholder.
d: 14.0; d1: 6.0; d2: 8.0; L: 48.0; L1: 28.0.
| MFR Part No. | 7393906422209 |
| Series | H |
| Head Type | Multiple Flute |
| Standards Met | ISO9001; ISO14001 |
| Tool Type | Counterbore |
| Shank Type | Weldon |
| Part Number | 1H-23.0 |
| Shank Diameter | 14mm |
| Overall Length | 48mm |
| Finish/Coating | Black Oxide |
| Number of Flutes | 3 |
| Product Type | Counterbore |
| Cutting Diameter | 23mm |
| Material Grade | K40 Micrograin |
| Material | Carbide |
