HP Beyond Drills Steel Without CoolantHigh-Performance Solid Carbide Drills
| Unit Measured | Metric |
| Adapter Style | Straight-Cylindrical |
| Helix Angle | 27.045 |
| Flute Length | 34mm | 34.0000mm |
| Drill Depth | 24mm | 24.0000mm |
| Drill Diameter | 6.5000mm |
| Material | Carbide |
| Functional Length | 77.7820mm |
| Coolant Supplied | No |
| MFR Part No. | 4111780 |
| Assembly Length | 41.782mm |
| Adapter Type | Cylindrical |
| Number of Flutes | 2 |
| Flute Construction | Helical Flute |
| Drill Point | 1.218mm |
| Overall Length | 79mm | 79.0000mm |
| Helix Type | Right Hand Helix/Flute |
| Clamping Length | 36mm |
| Finish/Coating | TiAlN |
| Drill Diameter Tolerance | 0.006000 to 0.021000mm |
| Primary Material | Steel |
| Adapter / Shank / Bore Diameter | 8.0000mm |
| Shank Length | 36.0000mm |
| Hand Preference | Right |
