MB-E0500-13-09 CoroCut Boring Bar

CoroCut MB is a high precision system for grooving, face grooving, profiling and pre-parting. The edge line of the cutting edge is sharp with a thin-layered coating, which in combination with the stability of the tools makes it ideal for internal machining.Features & Benefits- Internal turning, diameters from 10 mm- Turning, threading, parting and grooving- Close - Front-mounted exchangeable cutting tool- Sharp cutting edges- Geometries and grades for all materials- Carbide shanks for long overhangs- Through coolant- Easy fix clamping- Grooving tools in a large variety of widths and corner radii also for standardized grooves such as O-rings and circlip grooves.Application- Finish and precision machining at low feeds and speeds- For shallow grooves- Thread turning, turning, back boring, face grooving, profiling and pre-parting operations- Dedicated face grooving holder with nozzles for high precision coolant

Functional Length	55mm
MFR Part No.	12067683
Hand Preference	Neutral
Weight	159.2g
Connection Diameter	12.7mm
Maximum Overhang	30.7mm
Body Diameter	0.393701in
Damping Property	No
CoroPak	80
Coolant Exit Style	3
Coolant Entry Style	1
Through Hole Function Property	Yes
Unit Measured	Imperial
Body Material	Carbide
