Robot spindles are ideal for stationary applications in robot stations, machine tools and for installation in transfer lines. The exhaust air flow is at the front. The robot spindle is characterized by its very high concentricity in continuous use. It has a stainless steel collet mounting. Quick coupling, 3 mm collet, 2 keys.
| Power Output Without Oil | 100W |
| Air Supply Hose Outer Dia. | 2.7mm |
| Rotational Direction | Clockwise |
| At Idle | 0.32m\u00b3/min |
| Collet Group | 15 |
| Height | 30mm |
| Incl. Dia Collet | 3mm |
| Air Supply Hose Internal Dia. | 2.7mm |
| Exhaust Direction | Front |
| Rotational Speed Without Oil | 100000rpm |
| Length | 93.5mm |
| Inner Diameter | 2.7mm |
| Power Output | 100W |
| Under Load | 0.32m\u00b3/min |
