Robot spindles are ideal for stationary applications in robot stations, machine tools and for installation in transfer lines. The exhaust air flow of the air grinder is at the back. The robot spindle is characterized by its very high concentricity in continuous use. It has a stainless steel collet mounting and a planetary gear. Quick coupling, speed throttle, 6 mm collet, 2 keys.
| Air Supply Hose Outer Dia. | 11mm |
| Collet Group | 16 |
| Rotational Direction | Clockwise |
| Rotational Speed | 5800rpm |
| Height | 60mm |
| Length | 257mm |
| Under Load | 1.38m\u00b3/min |
| Incl. Dia Collet | 6mm |
| Inner Diameter | 11mm | 16mm |
| Exhaust Direction | Rear |
| Air Supply Hose Internal Dia. | 11mm |
| Power Output | 1100W |
| At Idle | 1.58m\u00b3/min |
