Robot spindles are ideal for stationary applications in robot stations, machine tools and for installation in transfer lines. The exhaust air flow of the air grinder is at the back. The robot spindle is characterized by its very high concentricity in continuous use. It has a stainless steel collet mounting. Quick coupling, 6 mm collet, 2 keys.
| Exhaust Direction | Rear |
| Air Supply Hose Outer Dia. | 10mm |
| Collet Group | 16 |
| Rotational Direction | Clockwise |
| Length | 234mm |
| Air Supply Hose Internal Dia. | 10mm |
| Power Output | 800W |
| Height | 46mm |
| Incl. Dia Collet | 6mm |
| At Idle | 1.15m\u00b3/min |
| Inner Diameter | 10mm |
| Rotational Speed | 17000rpm |
| Under Load | 0.95m\u00b3/min |
