40A4R050B32-SLN12X-C LN12 90 Tangential End Mill

Face mill with positive/negative geometry utilising 3 single-sided inserts. Cutting diameter of between 40mm and 53.5mm with a 45 approach angle and a 32mm Weldon shank according to DIN 1835B. 45mm usable and 120mm overall length, through coolant for face milling and chamfering with a maximum depth of cut of 6.4mm. Features and Benefits Internal coolant for improved tool life Improved chip evacuation provides high surface quality and reliability Carbide shim on cutter seating place for extra protection and durability Low vibrations and long tool life for both insert and cutter Typical Applications Hardened Metals Cast Iron Stainless Steel Steel Cast Steel High-temperature alloys Non-ferrous metals

Cutting Edge Angle	90\u00b0
Insert Shape	Rectangle
ISO Designation	40A4R050B32-SLN12X-C
Number of Inserts	4
Product Type	Tangential End Mill
MFR Part No.	8185958
Insert Size	1210
Toolholder Material	Steel
Height	120mm
Toolholder Style	Square Shoulder Mill
Maximum Cutting Diameter	40mm
Milling Application	Face Milling
