12.0MM 4FL Standard Carbide End Mill

For optimum performance and maximum swarf removal when plunging, slotting and routing in light alloys, brass, aluminium, non-ferrous and other soft materials. Manufactured to USCTi Standards. Their 4 flute design offers maximum rigidity for increased strength when cutting. Features and Benefits Carbide micrograin construction for increased strength 4 flutes for maximum rigidity Offfers maximum swarf removal when plunging, slotting and routing in soft and non-ferrous materials Standards Manufactured to USCTi Standards Notes Diameter: Over 1.00 ~ up to 6.00. Tolerance: +0.000, -0.050 Diameter: Over 6.00 ~ up to 25.00. Tolerance: +0.000, -0.080

Length Type	Regular
Material	Carbide
Finish/Coating	Bright
Shank Type	Plain Round
Plunge Type	Centre Cutting
Cutting Direction	Right Hand
Cutter Diameter	12.0mm
System of Measurement	Metric
Shank Diameter	12.0mm
Milling Cutter Type	End Mills
End Mill Type	End Mill
Standards Met	ANSI
Overall Length	76.0mm
Flute Type	Helical
Number of Flutes	4
Cutter Style	Square End
Helix Angle	30\u00b0
Flute Length	25.0mm
Coolant Delivery	External
