£4.62
Loading...
Short series slot drill with 3 flutes
| Series | S813HA |
| Finish/Coating | AlCrN |
| Cutter Style | Square End |
| Product Series | S813HA |
| Standards Met | DIN 6527 L |
| Flute Type | Helical |
| Shank Diameter | 12mm |
| Material | HM |
| Cutter Diameter | 12mm |
| End Mill Type | Slot Drill |
| System of Measurement | Metric |
| Unit of Measurement | Metric |
| Length Type | Regular |
| Length of Cut | Short |
| Helix Angle | 28\u00b0 |
| MFR Part No. | S813HA12.0 |
| Product Type | Slot Drills |
| Finish | AlCrN |
| Cutting Direction | Right Hand |
| Overall Length | 83.0mm |
| Number of Flutes | 3 |
| Shank | Cylindrical shank DIN 6535 HA |
| Flute Length | 22mm |
| Coolant Delivery | External |
| Shank Type | Plain Round |
| Shank Diameter Tolerance | H6 |
| ISO Designation | S |
| Milling Cutter Type | Slot Drill |
