Product Range: CoroDrill 862Tool Type: Solid carbide drillsSolid carbide and polycrystalline diamond (PCD) micro drills ideal for precision machining in small parts- Drill for micro holes < 3 mm diameter- Good hole entry and exit, tight hole tolerance- ACM (Advanced Chip Management) flute geometry for small and manageable chips
| Grade | GC34 |
| CoroPak | 12.1 |
| Cutting Diameter | 2.8mm |
| ISO Cutting Tool Material | Coated WC or Cermet |
| Through Hole Function Property | Yes |
| Unit Measured | Metric |
| Standards Met | COROMANT |
| Achievable Hole Tolerance | H9 |
| Overall Length | 84mm |
| Connection Diameter | 3mm |
| Rotational Speed Maximum | 27284 1/min |
| MFR Part No. | 26151197 |
| Usable Length | 22.9mm |
| Functional Length | 83.5mm |
| Coating Type | TiAlN |
| Usable Length Diameter Ratio | 8.18 |
| Point Angle | 140\u00b0 |
| Coating Process Type | PVD |
